Tag: Boeing 737

How to move Heavy Stuff without Wheels

I wanted to rotate the cockpit shell horizontally by 90 degrees (you may have read the article where we already had rotated it by 90 degrees vertically). The thing weighs around 600 kg and wheels are not an option when rotating in a circle. The idea was: build skis of wooden plates and use frying …

Continue reading

Fitting Custom Screens to the MIP

The journey has just begun, or as we say in german: Der Weg ist das Ziel. After adapting the nicely made upper part of the Boeing 737-800 MIP from SISMO Soluciones to the original Boeing 737-300 MIP stand below (see this post), the next task was to outfit the whole thing with proper electronics. I …

Continue reading

Making of the Integrated Standby Flight Display

The Integrated Standby Flight Display (ISFD) is used in all newer Boeing 737 jets. This instrument is thought to be a backup when all other (now digital) flight instruments fail. In the real aircraft it is a fully independent (in terms of power and sensors) and rather small replacement of the Primary Flight Display (PFD) …

Continue reading

Fitting the MIP to the real Cockpit

I have bought the high quality MIP with glareshield from SISMO Soluciones and wanted to put it on top of the original B737-300 MIP stand and then mount both things into the real B737-300 cockpit shell. Nice idea. Of course the MIP stand totally changed from the -300 to the -800 (the FMC&lowerCDU bay is …

Continue reading

Flight Management Computer using Rasperry Pi

Thanks to my colleague Piki from northern Germany and thanks to Dotsha747’s open source FMC PCB and hardware guidance I have been able to complete the first Flight Management Computer (FMC). It uses a Rasperry Pi 3B instead of the Rasperry Pi Zero recommended by Dotsha747 since I want to use a wired LAN connection …

Continue reading

J-Rails Mounted

Thanks to Pedro von SimuJabs who was able to exactly replicate the Boeing 737-300 J-Rails I could now mount the original cockpit seats. Original J-Rails are very hard to get and the often replicated Boeing 737NG J-Rails are not compatible to the Boeing 737 Classic mounting holes. At the end, I had to still move …

Continue reading

Thermal Insulation using Sheep Wool

There are all-natural thermal insulation materials out there. The Swiss company Fisolan AG is specialized in turning sheep wool into thermal insulation blankets ready to be used to insulate buildings … or commercial aircraft. Unlike glass wool the sheep wool blankets can be handled without health protection measures. So that is how the Cockpit looked …

Continue reading

Boeing 737 Flight Deck Project

Dear Friends of Flight Simulation In late September 2018 Jörg Weinmann, the head of simparts.de and simsystems.de, sold the following Boeing 737-330 cockpit shell on ebay and I could not resist to place a bid. It turned out that I was the only bidder since other potential buyers were frightened by the unknown and potentially …

Continue reading

Buttkicker (Füdligingger) under the seat

The Buttkicker Simulation Kit has arrived. After being sold out for years it is finally available again. It’s a fine piece of hardware. Connecting is easy. I’ve screwed the Transducer under the original B737 seat and it makes a difference during flight. What is needed now would be to add low frequency vibrations to individual …

Continue reading

Boeing 737 Flight Controls Completed

It took some time to rebuild the cockpit so that it would fit the simujabs control column and rudder pedal mechanics. The whole construction had to be raised by around 22 cm which enabled placing the column and rudder mechanics under the “double floor”. The result is fantastic. See yourself … Above images show the …

Continue reading
